Description
The 4.5″ x 12″ intercooler represents the sane limit of what can be fit behind the bumper bar before completely removing it. Substantial trimming required. The 10″ x 3.5″ is definitely the easiest fit and the lightest option.
With either 10″ or 12.5″ of height, and your choice of 3.5″ or 4.5″, this intercooler is rated up to 1000hp! These intercoolers feature a divided inlet to help route air to the top of the intercooler, eliminating heat soak the bottom of the intercooler, and dispersing the air more efficiently.
Treadstone Intercooler features superb quality highly efficient bar and plate construction. These quality cast end tanks ensure evenly distributed airflow and low-pressure drop. These intercoolers are now pressure checked to 150psi and come with a 1-year warranty against manufacture defect. Please view the picture above showing Treadstone’s high heat-dissipating internal fin design.
-Core Size, 12.5″ X 22″ X 4.5″ (12″x4.5″)
-Overall lenght 30″
-Less than 2psi pressure drop at max flow
-3″ inlet/outlet
-4.5″ core, 1469 CFM flow rate, 1000hp efficient, 1.5psi drop
- Core Size, 10.5″ X 22″ X 4.5″ (10″x4.5″)
- Overall lenght 30″
- 3″ inlet/outlet
- 1300CFM flow rate
- 860 HP efficient
- less than 2 psi pressure drop, at max flow
- weight 28lb
- Core Size, 12.5″ X 22″ X 3.5″
- Overall length:
- – Lip to Lip: 31″
- -End tank to End tank: 28″
- Less than 2psi pressure drop at max flow
- 3″ inlet/outlet
- 3.5″ core, 1142 CFM flow rate, 760hp efficient, 1.5psi drop
- Core Size, 10.5″ X 22″ X 3.5″ (10″x3.5″)
- Overall lenght 30″
- 3″ inlet/outlet
- 1000 CFM flow rate
- 666 HP efficient
- less than 2 psi pressure drop, at max flow
